★ 🎀 READY STOCK🎀 ★ Suitable For Compact Camera Battery COMPATIBLE (Canon Compact Camera / CCD/ Battery Charger)

Electrical Characteristics:

1. Input Voltage, Current, Frequency

1.1 AC Input Voltage: 100–240VAC
1.2 AC Input Frequency: 50/60Hz
1.3 AC Input Current: <100mA
1.4 DC Input Voltage: 12–24V (optional)
1.5 DC Input Current: ≤600mA

2. Output Characteristics
2.1 No-load Output Voltage: DC 4.2V–8.4V (reference value)
2.2 Load Output Voltage: DC 3V–4.3V (automatically adjusted according to battery voltage)
2.3 Charging Characteristics:

Indicator Current: 30–100mA
Charging Current: 550mA ±50mA (reference value)
All parameters are tested in an environment temperature of -10℃ ~ +45℃
3. Charging Indicator

No load (not charging) but power connected: LED Green
Charging: LED Red
Fully Charged: LED Green

4. Protection Function
Short-circuit Protection: The charger will not be damaged if the positive and negative terminals are shorted for 1 minute, and it can recover automatically.

5. Charging Method
Constant voltage and constant current charging mode.
